81007292 ALTIN TEXTIMA 8332/8333 FEED DOG 1.4 MM

€9.00

• Feed dog, overedge 1.4 mm • Suitable for Altin 8332, 8333 series • Fits to plate: 81006275, 81006090

81007293 ALTIN TEXTIMA 8332/8333 FEED DOG 2.0 MM

€9.00

• Feeder, overedge 2.0 mm • Suitable for Altin Textima 8332, 8333 • Fits to plate 81006275, 81006090

140XL037 TIMING BELT

€9.00

• Sewing machine driving belt • Suitable for: RIMOLDI, BROTHER BAS47 • Length: 355.60 mm (14") • Pitch: 5.08 mm • Teeth: 70 (Z70) • Width: 9.4 mm • Also works as: 930667 Rimoldi, 129479-000 Brother, 04-716 Kansai

240XL075 TIMING BELT

€9.00

• Sewing machine driving belt • Suitable for TEXTIMA 8431 • Also works as: 82103060, 82103058 • Length: 609.6 mm (24") • Width: 19 mm (0.75") • Pitch: 5.08 mm • Teeth (Z): 120

10x530 Z21 BELT

€9.00

• Optibelt-VB V-belt (toothed) • Width: 10 mm • Internal length: 530 mm • External length: 568 mm • Pitch: 5 mm • Teeth: 98

MPT95 TAPERED PULLEY DIN90 (95-90 mm)

€9.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Diameter (outer): 95 mm • Working diameter (inner): 90 mm • Also known as: DIN90, MPT95, MPT-95, MPT95-90

792-7260 DÜRKOPP ADLER 219 TOOTH BELT

€9.00

• Timing belt for DÜRKOPP ADLER 219 sewing machines • Also known as: 0792 007260, 0792007260, 792007260, 7927260 • Classification: 270XL037 • Length: 685.8 mm (27") • Width: 12.5 mm • Pitch: 5.08 mm • Teeth (Z): 135

146570-001 BROTHER B551-069 MAIN FEED DOG

€9.00

• Main Feed Dog • Suitable for BROTHER B551-069 sewing machine • Also known as: 146570 001, 146570-001, 146570001

146751-001 BROTHER B531 DIFFERENTIAL FEED DOG

€9.00

• Differential feed dog • Suitable for BROTHER B531 sewing machines • Also known as: 146751 001, 146751-0-01, 146751001 • Also works as: S16462-001

118-82800 JUKI MOR-..16 MAIN FEED DOG

€9.00

• Main Feed Dog • Suitable for machines JUKI MOR-..16 series • Also known as: 118-82800, 11882800 • Also works as: 191-82302, 19182302, FD60828, FD-828, U94105B

124-76206 JUKI MO-3316 MAIN FEED DOG

€9.00

• Main Feed Dog • Suitable for overlock JUKI MO-3316 • Also known as: 124-76206, 12476206 • Also works as: 3700-76206

149939-001 BROTHER LT-842-3 FEED DOG 295 (3/8")

€10.00

• Feed dog for medium materials (M) • Suitable for 2-needle machines BROTHER LT-842-3 • Also known as: 149939 001, 149939-0-01, 149939001 • Needle distance: 9.5 mm (3/8")

91-015 558-04/004 PFAFF 1244 PRESSER FOOT C1.8

€10.00

• Presser Foot Cx1,8 • Suitable for heavy duty machines Pfaff 1244 • Also known as: 91-015558-04/004, 91015558-04/004, 9101555804/004, 9101555804004

PFAFF 91-127 151-05 FRICTION LINING

€10.00

• Friction Lining for Pfaff 3306 • Made from cork • Also known as 9112715105000, 9112715105, 91-127151-05, 91127151-05

99-135 585-05 PFAFF 290 BELT 1040-8M-16

€10.00

• Toothed Belt 1040-8M-16 • Width 32 mm, L=1490 mm, Z=302 • Suitable for Pfaff 290 class machines • Also known as: 99-135585-05, 99135585-05, 9913558505, 9913558505000

91-047 260-04/004 PFAFF 480 FEED DOG B

€10.00

• Feed Dog B • Suitable for Pfaff 480 series sewing machines • Also known as: 91-047260-04/004, 91047260-04/004, 9104726004004, 91-047260-04B • Can be used as: 91047260-04/005 • Compatible with needle plate: 91-048673, 91-058129

102-38509 JUKI LH-3168-7 FEED DOG (295x2.0)

€10.00

• Feed dog for 2-needle sewing machine • Suitable for JUKI LH-3168-7 • Also known as: 102-38509, 10238509 • Needle distance: 9.5 mm (3/8") • Needle hole Ø : 2.0 mm

115-28304 JUKI MOG-2516FF6 FEED DOG

€10.00

• Main Feed Dog • Suitable for JUKI MOG-2516FF6 • Also known as: 115-28304, 11528304 • Also works as: FD60840, 377680

118-85803 JUKI MO-2516G-DD6 DIFFERENTIAL FEED DOG

€10.00

• Differential Feed Dog • Suitable for JUKI MO-2516G-DD6 sewing machine • Also known as: 118-85803, 11885803

118-85209 JUKI MO-2516-DD4 DIFFERENTIAL FEED DOG

€10.00

• Differential Feed Dog • Suitable for JUKI MO-2516-DD4 sewing machine • Also known as: 118-85209, 11885209

124-76701 JUKI MO-3304-0F6-50H MAIN FEED DOG

€10.00

• Main Feed Dog • Suitable for overlock JUKI MO-3304-0F6-50H • Also known as: 124-76701, 12476701

B-1613-012-I00 JUKI DDL FEED DOG 1.15 (I)

€10.00

• Feed Dog (I) • Suitable for JUKI DDL- series sewing machines • Also known as: B1613-012-I00, B1613012-I00, B1613012I00, B1613012IOO • Fits to throat plate: B1109-012-I00, B1109012I00 • P=1.15 mm

B-1613-012-C00 JUKI DDL FEED DOG 1.5 (C)

€10.00

• Feed Dog (C) • Suitable for JUKI DDL- series sewing machines • Fits to throat plate: B1109-012-C00, B1109012C00 • P=1.5 mm • Also known as: B1613-012-C00, B1613012-C00, B1613012C00, B1613012COO • Can be used as Orsha 8714A

D-1837-555-BAA-A JUKI DDL BOBBIN CASE

€10.00

• Bobbin Case Assembly • Suitable for Lockstitch Machine JUKI DDL • Original JUKI #: D-1837-555-BAA-A, D1837-555-BAA-A, D183555BAAA • Also known as: BC-DB1-NBL6, BCDB1NBL6, 52237NBL6

17-4240-1 KANSAI DBF-1404PMD 1-1/2" PRESSER FOOT 38.1 MM

€10.00

• Presser foot (1-1/2) • Needle distance 38.1 mm • Compatible with 4-needle machines DFB-1404PMD type Kansai Special • Also known as: 17-424, 1742401, 17-4240-1

204394 PEGASUS U32-34 MAIN FEED DOG

€10.00

• Main Feed Dog • Suitable for PEGASUS U32-34 sewing machines • Also known as: 2043940 • Also works as: 208064

16407-9 SEIKO LSW-BLK BOBBIN CASE CAP ASSY

€10.00

• Bobbin Case Cap Complect • Suitable for sewing machines SEIKO LSW-27BLK • Also known as: SCP-BL, SCPBL • Works as SEIKO part #: 16407-9C, 16407-9

502682 SINGER 457 ARM SHAFT CONNECTING BELT PULLEY

€10.00

• Pulley # 502682 • Suitable for Singer 457 series machines • Works with belt 502508

P69RH-1/4 HINGED RIGHT PIPING FOOT 1/4 (6.4 MM)

€10.00

• Hinged right piping / cording foot • Suitable for lockstitch machines • Also known as: P69RH-1/4, P69RH1/4 • Pipe size: 6.4 mm (1/4")

CL25 LEFT COMPENSATING FOOT (2.5 MM)

€10.00

• Hinged left compensating foot 2.5 mm • Suitable for lockstitch machines • Also known as: CL-25 • Can be used as: NL2.5; CL3/32

CL30 LEFT COMPENSATING FOOT (3.0 MM)

€10.00

• Hinged compensating foot left 3.0 mm • Suitable for lockstitch machines • Also known as: CL-30 • Can be used as: CL1/8, CL32

CL40 LEFT COMPENSATING FOOT (4.0 MM)

€10.00

• Compensating left foot 4.0 mm • Suitable for lockstitch machines • Also works as: NL40, CL5/32S

S570D3/16-1/32 DOUBLE EDGE GUIDE FOOT (4.8-1.0 MM)

€10.00

• Hinged presser foot with double side edge guide • Suitable for 2-needle machines (e.g. Juki LH- series) • Needle distance: 4.8 mm (3/16") • Edge guide: 1.0 mm (1/32") • Also works as: PD112B3/16

OCEL 1500/200 CLUTCH DISK

€10.00

• Clutch / friction disk 1500/200 • Size: 125 x 4 mm • Also known as: 5512

PANASONIC MTSN5906501 CORK

€10.00

• Moving disk asm. for Juki & Singer • Also known as 993190017, 490828

12463H(R) RIGHT RAISING FOOT 3/8 (9.5 MM)

€10.00

• Hinged right raising presser foot 9.5 mm (3/8") • Suitable for lockstitch machines • Also known as: 12463HR3/8, 12463H3/8, 12463HR, 12463H, P816 • Can be used as: SP18R3/8, SP18-3/8, 36465-9.5

CF 555 BINDER FEED DOG FOR JUKI DDL

€10.00

• Binder feed dog • Suitable for binder (SET): GO 122, GO 123 • Fits to JUKI DDL sewing machine: e.g. 5550, 9000 • Also known as CF 555, CF555

4047C TREASURE FEED DOG

€10.00

• Feed dog • Suitable for Treasure sewing machines • Can be used as: 96-795846-00

9231813 CERIM CK23SZ BRIDGE FB5006 50A-60V

€10.00

• Bridge FB5006, 50A-60V • Suitable for shoe-making machine Cerim CK23SZ • Also works as: 9232043

MB-470 POSITRACTION BELT

€10.00

• Sewing machine driving belt • Suitable for Kenkemore Long machine • Length: 470 mm (18-1/2") • Diameter: 150 mm (approx) • Teeth: 116 • Also known as: MB470, TBPV/1812

50342R UNION SPECIAL 368U TOOTH BELT (220XL050)

€10.00

• Timing belt • Also works as: 50342CJ, PK-220, 220XL050 • Suitable for UNION SPECIAL 368U • Length: 558.8 mm (22") • Pitch: 5.08 mm • Teeth: 110 • Width: 13 mm

MPT130 TAPERED DIN PULLEY (130-125 mm)

€10.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Diameter (outer): 130 mm • Working diameter (inner): 125 mm • Also known as: DIN125, MPT130, MPT-130

MPT100 TAPERED PULLEY DIN95 (100-95 mm)

€10.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Diameter (outer): 100 mm • Working diameter (inner): 95 mm • Also known as: DIN95, MPT100, MPT-100, MPT100-95

MPT105 TAPERED PULLEY DIN100 (105-100 mm)

€10.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Diameter (outer): 105 mm • Working diameter (inner): 100 mm • Also known as: DIN100, MPT105, MPT-105, MPT105-100 • Also works as: DIN42692 106

MPT112 TAPERED PULLEY DIN106 (112-106 mm)

€10.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Diameter (outer): 112 mm • Working diameter (inner): 106 mm • Also known as: DIN106, MPT112, MPT-112, MPT112-106 • Also works as: DIN42692 112

MPT118 TAPERED PULLEY DIN112 (118-112 mm)

€10.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Diameter (outer): 118 mm • Working diameter (inner): 112 mm • Also known as: DIN.112, MPT118, MPT-118, MPT118-112

MPT120 TAPERED DIN PULLEY (120-115 mm)

€10.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Suitable for MO Fulsub • Diameter (outer): 120 mm • Working diameter (inner): 115 mm • Also known as: MPT120, MPT-120, MPT120-115

MPT124 TAPERED DIN PULLEY (124-118 mm)

€10.00

• V-belt pulley / Motor pulley • Tapered (MP-T, DIN) • Suitable for JUKI DDL-8700 • Diameter (outer): 124 mm • Working diameter (inner): 118 mm • Also known as: DIN.118, MPT124, MPT-124

BC-HTH(E) HIROSE BOBBIN CASE FOR HTH HOOK

€10.00

• Bobbin Case (with Spring) • Suitable for HIROSE HTH series hook • Also known as: BC-HTH(E), BC-HTH-E, BCHTHE

208500 PEGASUS L32 PRESSER FOOT 2.0

€10.00

• Presser Foot 2.0 • Suitable for PEGASUS L32 sewing machines • Also known as: P500
